Carbon Fiber Reinforced PPS Rods & Sheets (CF10%–50%)
Continuous CF Fabric & Short CF Grades | 4x Stiffness | Aerospace Metal Replacement
We supply Carbon Fiber Reinforced PPS Rods & Sheets (available in Short CF 10%–35% and 50% Continuous Woven Carbon Fiber Fabric CFRTP composites). Engineered for aerospace and heavy-duty structural components, our CF-PPS stock shapes offer 4x the stiffness of short-fiber plastics, ultra-lightweight metal replacement, and continuous heat resistance over 200°C. Fully stress-relieved for precision CNC machining.
Submit your required rod diameter, sheet thickness, or component drawing below for a fast factory-direct quote.
Product information
Published information supports preliminary product selection. Confirm the exact grade, dimensions, tolerances, documentation and application suitability with the quotation for your order.
Description
Combining semicrystalline PPS resin with carbon fiber reinforcement (short fibers or 50% continuous woven carbon fabrics), our CF-PPS stock shapes represent the pinnacle of high-modulus thermoplastic composites.
Designed to replace aluminum, titanium, and stainless steel in aviation and high-speed industrial machinery, CF-PPS delivers structural stiffness, minimal creep, and zero corrosion at up to 50% lower weight than aluminum.
Composite Performance Matrix
| Property / Feature | Short CF PPS (10%–30% CF) | 50% Continuous CF Fabric PPS | Aluminum Alloys (6061/7075) |
| Flexural Stiffness | High | Ultra-High (4x vs Short CF) | High |
| Component Weight | 40% Lighter than Metal | 50% Lighter than Metal | Baseline (Heavy) |
| Continuous Heat Limit | 200°C+ | 200°C+ | Strength drops at >150°C |
| Corrosion Resistance | Zero Corrosion | Zero Corrosion | Susceptible to oxidation |
Core Engineering Advantages
-
4x Mechanical Stiffness
Our 50% continuous woven carbon fiber fabric plates align high-modulus fibers along stress directions, delivering flexural stiffness over 4 times higher than conventional short-fiber reinforced plastics. -
Aerospace Weight Reduction
Replaces structural metals (aluminum/titanium) to reduce component weight by up to 50% while maintaining structural rigidity, directly lowering fuel consumption and dynamic inertia. -
Extreme Environmental Stability
Maintains tight sub-micron tolerances across severe temperature and humidity fluctuations. Features intrinsic UL94 V-0 flame retardancy, low creep, and resistance to acids, alkalis, and aviation fuels.
Engineering Limitations & Trade-offs
To ensure optimal component engineering, please evaluate the following CF-PPS material boundaries:
-
Directional Strength (Anisotropy ): For 50% continuous fabric plates, maximum mechanical strength follows the fiber alignment. Multi-axis load designs must account for fiber orientation.
-
Tooling Wear during Machining : Carbon fiber is highly abrasive. PCD (Polycrystalline Diamond) or diamond-coated CNC tools are strongly recommended to prevent rapid tool wear and edge delamination.
-
Material Cost: Premium pricing compared to glass-filled or unfilled PPS; recommended specifically for weight-critical or high-stress structural parts.
Target Applications
-
Aerospace & Aviation: Aircraft landing gear brackets, wing access panels, fuel tank covers, cabin interiors, nose cones.
-
High-Speed Industrial Machinery: Robotic arm beams, high-speed reciprocating guides, drone structural frames.
-
Automotive & Racing: High-performance engine covers, lightweight structural brackets, suspension components.
Quick Order Checklist
-
Form & Dimensions: Rod Diameter (mm) or Sheet Thickness × W × L (mm) / Cut-to-Size.
-
CF Grade Option: Short CF (10%–35%) or 50% Continuous Woven CF Fabric (CFRTP).
-
Quantity: Number of rods, plates, or machined cut pieces.
Material overview
Understanding PPS (Polyphenylene Sulfide)
Why engineers use it
- Broad chemical resistance for many industrial fluids and process environments.
- Low moisture uptake and good dimensional stability.
- Useful electrical insulation and inherent flame-resistance characteristics.
- Reinforced grades can provide high stiffness and repeatable molded dimensions.
- Often offers a practical cost/performance position below PEEK.
Limits to consider
- Unfilled PPS can be relatively brittle and design details strongly affect impact performance.
- Glass or mineral reinforcement changes shrinkage, anisotropy and machining behavior.
- Oxidizing media and actual high-temperature chemicals still require compatibility review.
- Weld lines, sharp corners and molding orientation can become structural weak points.
- It should not be selected from chemical-resistance charts alone.
Grades and product forms
PPS is commonly supplied unfilled or reinforced with glass fiber, mineral filler, carbon fiber or combined systems. The filler package changes stiffness, movement, surface finish, conductivity and wear. Pellets suit volume molding, while sheet, rod or finished parts may be preferable for prototypes and lower-volume production.
Performance points to review
| Evaluation area | Why it matters | Information to provide |
|---|---|---|
| Temperature behavior | Useful performance under elevated or changing temperature | Continuous and peak temperature, cycle length and time at load |
| Mechanical response | Strength and stiffness must match the real part geometry | Load direction, stress level, impact and fatigue expectations |
| Environmental resistance | Fluids, cleaning agents and atmosphere can change service life | Chemical name, concentration, temperature and exposure time |
| Dimensional control | Tight-tolerance parts depend on both material and processing | Finished dimensions, tolerances and assembly conditions |
| Electrical or insulation needs | Electrical requirements may influence grade and thickness | Voltage, dielectric, conductivity or insulation target |
These are engineering discussion points, not guaranteed property values. Final acceptance criteria should be agreed for the selected grade, process and order.
Typical application directions
These examples show where the material may be evaluated. They do not replace a suitability review for the finished component.
Fabrication and processing preparation
Share the finished part drawing as well as the requested rod diameter and length. This makes it possible to discuss machining allowance, tolerance, cut length, quantity and whether a closer starting size could reduce waste.
Where the application is critical, define what a successful trial looks like before material is ordered: dimensions after processing, visual condition, mechanical response, assembly fit or another measurable result.
When another material may be better
PEEK may be preferred when toughness or a broader high-temperature performance margin is required. PPS can be the more practical solution when chemical resistance, stiffness, repeatable molding and cost control are the central requirements.
We recommend sharing the current material and the reason it is being reconsidered. Cost, processability, supply form and inspection burden belong in the decision alongside technical performance.
Information needed for an accurate quotation
A useful RFQ reduces follow-up questions and helps us distinguish between a material request and a finished-part requirement.
| Product form | Raw material, stock shape, semi-finished blank or completed part |
|---|---|
| Dimensions | Nominal size, finished size and tolerances |
| Quantity | Trial quantity, first order and estimated annual demand |
| Application | Part function and current material, if any |
| Operating temperature | Continuous range, peak temperature and cycle duration |
| Environment | Chemicals, gases, moisture, pressure, vacuum or outdoor exposure |
| Mechanical duty | Load, speed, impact, wear and mating components |
| Documentation | Drawing revision, inspection, traceability or compliance needs |
Frequently asked questions
Can I request a sample or trial quantity?
Trial quantities can be discussed according to product form and availability. Tell us what you need to prove during the trial, the intended process and the expected production quantity if the test succeeds.
Do you provide a data sheet or material documentation?
Available documentation depends on the selected material and supply route. List the documents required by engineering, purchasing or quality when you inquire so they can be checked before quotation.
Can the grade be selected from a product name alone?
No. Similar product names can cover different grades, colors, fillers and processes. Selection should be based on the finished application, environment and required property balance.
Can you supply custom dimensions or finished parts?
Custom sizes, blanks or finished parts can be reviewed where appropriate. A drawing with tolerances, quantity and material requirement is the best basis for quotation.
How should we evaluate an alternative to our current material?
Share the current grade, the part’s service conditions and the reason for changing it. A useful comparison looks at failure mode, processing, life, inspection and total project cost—not only a single property value.
What determines lead time?
Lead time depends on product form, grade, size, quantity, documentation, machining and current availability. Confirm the required delivery date and destination with the RFQ rather than assuming a standard schedule.
Send the drawing, application and quantity. We will use the project details to prepare a practical material and supply discussion.
